Download specification and wiring diagram












The DK9520 is mainly designed for a stand-alone electric door lock installation
Its 5 amp single output relay provides N.C. and N.O. dry contacts for an electric door strike and is virtually compatible with any electric locking devices

Main features
12-24V AC/DC operation
Over 100 Million code combinations
100 User codes with 4-8 digits
Operates fail-safe or fail-secure locking device
Door lock Inhibit authorization
One 5 Amp relay output with N.C. & N.O. contacts
Auto or manual code entry
Output activation announcer
Pacifier tone Inhibit control
Egress Input for door remote triggering
All features are keyboard programmable
Non-volatile memory in power failure
Flush or surface mount

Size : 116h X 72w X 43d

Click here for a larger image

People who bought this item also bought:

Download specification and wiring diagram












Stainless steel surface mount keypad with rain hood - ideal for external use
Aluminium front plate with blue illuminated buttons
21 user codes
Fully programmable
2 relay output
Toggle facility on relay 2
3 LED status
Non volatile memory
12v & 24v DC

Size: 120h x 72w x 65d

Click here for a larger image

People who bought this item also bought:

Download specification and wiring diagram












The DK2850 is a full feature keypad system. It consists of 2 relay outputs controlled by 2
groups of independent user codes. Output 1 is a 5 amp rating relay providing both N.C.
and N.O. dry contacts for door strike, Output 2 is a 1 amp rating relay also providing
N.C. and N.O. dry contacts for other control applications, such as the controlling of an alarm
system. Three on board LED lamps are wired internally to indicate the operation status
of the outputs 1 and 2 and the system status. The keypad utilizes terminal block for all
the external connections

Main features
12-24V AC/DC operation
Back-lit metal button keypad
1.5mm Stainless steel face plate
Vandal resistant & weatherproof
Die cast black metal housing
Dual relay output
100 User PIN for output 1
10 User PIN for output 2
Surface mount or post mounting
Fits single gang flush mount box

Size: 125h X 79w X 46/54 (d: bottom side/upper side) mm

Click here for a larger image
