Description & Specifications:
Access Control System inc. Power Supply, Key Fob Reader, Vandal Resistant Exit Button, Emergency Break Switch & Magnetic Lock & Bracket
Overview
Access Control Kit 16 is a comprehensive key fob entry system designed for standard access control requirements in homes, offices, and other properties. The kit includes a magnetic lock with a release bracket, an exit button, an emergency break switch with a protective cover, a power supply, and a key fob door reader.
Specifications
Connection Drawings & Manuals
- SR2-X Manual
- Magnetic Lock 'ZL' Bracket Installation Guide
Magnetic Lock (600-S) A slimline, surface-mounted mini magnetic lock.
- Power Input: 12V/24V DC (selectable via internal jumper)
- Holding Force: 272kg (600lbs)
- Current Draw: 500mA @ 12V DC | 250mA @ 24V DC
- Magnet Dimensions: 250mm (L) x 42mm (W) x 26mm (D)
- Armature Plate Dimensions: 185mm (L) x 38mm (W) x 12mm (D)
Emergency Break Glass Switch A green, surface-mounted, resettable emergency switch.
- Features: Includes a clear protective cover and one reset key.
- Connections: Single pole with C/NO/NC outputs.
- Dimensions: 90mm (H) x 88mm (W) x 56mm (D)
Exit Button A durable, surface-mounted exit button.
- Construction: 2mm stainless steel facia with an alloy back box.
- Rating: IP66 rated for external use.
- Connections: Changeover contacts (C/NO/NC).
- Dimensions: 85mm (H) x 85mm (W) x 42mm (D)
SR2-X Proximity Card Reader A compact, weather-resistant, multi-function card reader. It can operate as a self-contained unit or as a standalone Wiegand output reader for PC-based systems.
- User Capacity: 1,000 users (987 common, 10 visitor, 2 panic, 1 authorized).
- Programming: Manual and remote control programming. PIN access is available for the administrator.
- Data Transfer: User data can be transferred between up to 9 connected units.
- Construction: Epoxy resin-filled ABS plastic body.
- IP Rating: IP66 (weather resistant).
- Voltage: 9-18V DC input.
- Current: 40mA.
- Reading Range: 20mm - 60mm.
- Card Compatibility: EM Wiegand (125Khz) or Mifare Classic (13.56Mhz) cards and fobs.
- Outputs: 1 x 2amp relay (N.C/N.O contacts), Wiegand output.
- Dimensions: 103mm (H) x 48mm (W) x 20mm (D).
Power Supply A regulated, switch-mode power supply in a small ivory white cabinet.
- Output: 13.8V DC, 1amp.
- Features: Additional battery charging output, electronic deep discharge protection, and LED indicators for mains, DC output, and battery status.
- Dimensions: 225mm (H) x 195mm (W) x 75mm (D).
- In addition to the above specifications, this effortless data transfer can be done wirelessly through Bluetooth connectivity. This feature allows for convenient and quick data transfer between multiple units without the need for any cables or cords.
FAQs
Is the lock suitable for external use? No, the lock connections are not weatherproof and must be concealed from direct rain.
Can the SR2-X card reader be used outside? Yes, it is IP66 rated, offering complete protection against dust and powerful jets of water.
Does the SR2-X reader work with any standard RFID or Mifare fob? Yes, it is compatible with both Wiegand RFID 125Khz and Mifare Classic 13.56Mhz technologies.
How do I program new fobs? Programming is simple using the included Master Add/Delete card or the remote control. We advise recording the 10-digit Unique ID (U.I.D) number printed on each fob for easier management.
What if I lose the Master Add/Delete card? You can reset the SR2-X reader and create a new Master card from any fob. This process will not delete your existing user fobs.
How do I delete a lost fob? You can either use the Master Delete card with the fob present or use the remote control to delete it by entering its 10-digit U.I.D number.
Can I use two readers for entry and exit on one door? Yes, simply purchase an additional SR2-X reader.
Can I program the same fob to work with multiple readers? Yes. You can connect up to nine SR2-X readers and transfer the user data from the primary unit to all others. Refer to page 7 of the manual for instructions.
Can this system operate my automatic gate? Yes. Please consult the downloadable wiring diagrams for setup instructions.
What type of cable do I need? Standard 3- or 4-pair alarm cable, available at most electrical or DIY stores, is recommended.
Tech Tips
- Powering the Magnetic Lock: Before powering on, double-check that the lock is wired correctly for either 12V DC or 24V DC. Incorrect wiring can cause overheating, locking failure, and eventual system damage.
- Maintenance: Periodically clean the surfaces of the magnet and armature plate with a light oil to ensure optimal performance.
What's Included
- 1 x SR2-X Card Reader with Master Add/Delete Card and Remote Control
- 1 x DRBSS02S-PTE Stainless Steel Surface-Mounted Exit Button
- 1 x Magnetic Lock Release with Adjustable ZL Brackets (Fail-safe, requires power to lock)
- 1 x Resettable Emergency Break Glass Switch with Protective Cover
- 1 x 12V DC Power Supply
